UHMWPE dredging pipeline

没有此类产品
I want to make an inquiry
Description
Features
Specifications
Application

Ultra-high molecular weight polyethylene (UHMWPE) is a kind of engineering thermoplastics with more than 3 million viscosity-average molecular weight. It differs from PE standard grades in its very high degree of polymerization. Ultra-high molecular weight polyethylene pipe has superior performance over conventional HDPE pipe

The nominal pressure rating of UHMWPE pipes etc. is from 0.6 MPa to 2.0 MPa and UHMWPE composite pipe can reach 6.4 MPa.



size:DN30-DN1200

Supply uhmwpe pipe with plain-ends or with flared ends with or without flanges.

Length: 5.8m or 11.8m loaded in 20 or 40 inch container.

We can also customized as your requirements.



Product Name

China factory supply uhmwpe dredging pipeline

Material

UHMWPE and steel

Clour

Balck, White, Yellow, or as request

Size

DN30-DN1200mm,

Length :depand on order
Thickness:6-30mm

certification

ISO,CE,SGS,ROHS

Working temperature

-265 degrees to 85 degrees

Working pressure0.6

Mpa-2.5Mpa

connection

Steel Flange

Standard

ISO

Packing

standard package for sea transportation,loaded in container

characteristic

Roughness:0.00022
Elongation:≥350%
Coefficient of friction:0.0084
